NSK马达广泛应用于PCB行业的钻靶机及金手指斜边机
NSK气钻SPINDLE
编号气钻名称外径转速功率
1021AM-300R22.8mm30,000min-1（rpm）57W
1083AM-300L22.8mm30,000min-1（rpm）57W
1018AM-300RA22.8mm30,000min-1（rpm）57W
1084AM-300LA22.8mm30,000min-2（rpm）57W
1079AM-310R22.8mm30,000min-2（rpm）108W
1085AM-310L22.8mm30,000min-2（rpm）108W
1081AM-310RA22.8mm30,000min-2（rpm）108W
1082AM-310LA22.8mm30,000min-2（rpm）108W
1071AM-600R22.8mm58,000min-1（rpm）76W
2512AM-600RA22.8mm55,000min-1（rpm）69W
8220NR-235122.8mm30,000min-1（rpm）
1020NR-30122.8mm30,000min-1（rpm）
1020NR-230122.8mm30,000min-1（rpm）
2511NR-31022.8mm30,000min-1（rpm）
1073NR-60122.8mm60,000min-1（rpm）
1801AM-2526R25mm24,000min-1（rpm）130W
1802AM-2526L25mm24,000min-1（rpm）130W
1803AM-2526RA25mm22,000min-1（rpm）120W
1804AM-2526LA25mm22,000min-1（rpm）120W
 8333 EM25-5000-J4 25mm 50,000min-1（rpm） 125W
1819NR-255125mm50,000min-1（rpm）
1809NR-253225mm30,000min-1（rpm）
1797AM-3020R30mm19,000min-1（rpm）130W
1798AM-3020L30mm19,000min-1（rpm）130W
1799AM-3020RA30mm18,000min-1（rpm）125W
1800AM-3020LA30mm18,000min-1（rpm）125W
9027EM-40530mm40,000min-1（rpm）270W
1565NR-402E30mm40,000min-1（rpm）
1565NR-403E30mm40,000min-1（rpm）
1566NR-453E30mm50,000min-1（rpm）
1534AMS-20R53mm2,200min-1（rpm）131W
1528AMS-50R53mm4,000min-1（rpm）131W
1529AMS-150R53mm15,000min-1（rpm）132W
1530AMS-25047mm25,000min-1（rpm）


NSK气钻控制器 NE145、NE147、NE72、NE123、NE211
名 称   电 源 频 率 功 率     尺 寸
NE72AC110V50/60Hz75WW225×D195×H97mm
NE123AC200-240V50/60Hz150WW430×D487×H177mm
NE145AC100-240V50/60Hz92WW108×D156×H175mm
NE147AC100-240V50/60Hz180WW210×D290×H97mm
NE211AC100-240V50/60Hz350WW88×D138×H238mm
